| Product Code |
色温 CCT |
显指 CRI |
Luminous Flux （lm） |
Efficacy （lm/w） |
Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2181-072-1212-P2280-X | 2200K | 80 | 0 | 5185 | 5575 | 152 | 34.0 |
| P2181-072-1212-P2580-X | 2500K | 0 | 5372 | 5777 | 157 | 34.0 | |
| P2181-072-1212-P2780-X | 2700K | 0 | 5560 | 5979 | 163 | 34.0 | |
| P2181-072-1212-P3080-X | 3000K | 0 | 5861 | 6302 | 172 | 34.0 | |
| P2181-072-1212-P3580-X | 3500K | 0 | 6011 | 6464 | 176 | 34.0 | |
| P2181-072-1212-P4080-X | 4000K | 0 | 6161 | 6625 | 180 | 34.0 | |
| P2181-072-1212-P4580-X | 4500K | 0 | 6199 | 6665 | 182 | 34.0 | |
| P2181-072-1212-P5080-X | 5000K | 0 | 6236 | 6706 | 183 | 34.0 | |
| P2181-072-1212-P5780-X | 5700K | 0 | 6236 | 6706 | 183 | 34.0 | |
| P2181-072-1212-P6580-X | 6500K | 0 | 6161 | 6625 | 180 | 34.0 | |
| P2181-072-1212-P2290-X | 2200K | 90 | 50 | 4396 | 4727 | 129 | 34.0 |
| P2181-072-1212-P2590-X | 2500K | 50 | 4584 | 4929 | 134 | 34.0 | |
| P2181-072-1212-P2790-X | 2700K | 50 | 4771 | 5131 | 140 | 34.0 | |
| P2181-072-1212-P3090-X | 3000K | 50 | 5034 | 5413 | 147 | 34.0 | |
| P2181-072-1212-P3590-X | 3500K | 50 | 5185 | 5575 | 152 | 34.0 | |
| P2181-072-1212-P4090-X | 4000K | 50 | 5260 | 5656 | 154 | 34.0 | |
| P2181-072-1212-P4590-X | 4500K | 50 | 5316 | 5716 | 156 | 34.0 | |
| P2181-072-1212-P5090-X | 5000K | 50 | 5372 | 5777 | 157 | 34.0 | |
| P2181-072-1212-P5790-X | 5700K | 50 | 5372 | 5777 | 157 | 34.0 | |
| P2181-072-1212-P6590-X | 6500K | 50 | 5297 | 5696 | 155 | 34.0 | |
| P2181-072-1212-P2797-X | 2700K | 97 | 90 | 3738 | 4020 | 109 | 34.0 |
| P2181-072-1212-P3097-X | 3000K | 90 | 4039 | 4343 | 118 | 34.0 | |
| P2181-072-1212-P3597-X | 3500K | 85 | 4189 | 4505 | 123 | 34.0 | |
| P2181-072-1212-P4097-X | 4000K | 85 | 4339 | 4666 | 127 | 34.0 | |
| P2181-072-1212-P4595-X | 4500K | 95 | 80 | 4530 | 4871 | 133 | 34.0 |
| P2181-072-1212-P5095-X | 5000K | 80 | 4578 | 4923 | 134 | 34.0 | |
