| Product Code |
色温 CCT |
显指 CRI |
Luminous Flux （lm） |
Efficacy （lm/w） |
Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2171-036-1206-P2280-X | 2200K | 80 | 0 | 2630 | 2827 | 154 | 34.0 |
| P2171-036-1206-P2580-X | 2500K | 0 | 2723 | 2928 | 160 | 34.0 | |
| P2171-036-1206-P2780-X | 2700K | 0 | 2817 | 3029 | 165 | 34.0 | |
| P2171-036-1206-P3080-X | 3000K | 0 | 2968 | 3191 | 174 | 34.0 | |
| P2171-036-1206-P3580-X | 3500K | 0 | 3043 | 3272 | 178 | 34.0 | |
| P2171-036-1206-P4080-X | 4000K | 0 | 3118 | 3353 | 183 | 34.0 | |
| P2171-036-1206-P4580-X | 4500K | 0 | 3137 | 3373 | 184 | 34.0 | |
| P2171-036-1206-P5080-X | 5000K | 0 | 3155 | 3393 | 185 | 34.0 | |
| P2171-036-1206-P5780-X | 5700K | 0 | 3155 | 3393 | 185 | 34.0 | |
| P2171-036-1206-P6580-X | 6500K | 0 | 3118 | 3353 | 183 | 34.0 | |
| P2171-036-1206-P2290-X | 2200K | 90 | 50 | 2235 | 2403 | 131 | 34.0 |
| P2171-036-1206-P2590-X | 2500K | 50 | 2329 | 2504 | 136 | 34.0 | |
| P2171-036-1206-P2790-X | 2700K | 50 | 2423 | 2605 | 142 | 34.0 | |
| P2171-036-1206-P3090-X | 3000K | 50 | 2554 | 2747 | 150 | 34.0 | |
| P2171-036-1206-P3590-X | 3500K | 50 | 2630 | 2827 | 154 | 34.0 | |
| P2171-036-1206-P4090-X | 4000K | 50 | 2667 | 2868 | 156 | 34.0 | |
| P2171-036-1206-P4590-X | 4500K | 50 | 2695 | 2898 | 158 | 34.0 | |
| P2171-036-1206-P5090-X | 5000K | 50 | 2723 | 2928 | 160 | 34.0 | |
| P2171-036-1206-P5790-X | 5700K | 50 | 2723 | 2928 | 160 | 34.0 | |
| P2171-036-1206-P6590-X | 6500K | 50 | 2686 | 2888 | 157 | 34.0 | |
| P2171-036-1206-P2797-X | 2700K | 97 | 90 | 1890 | 2032 | 111 | 34.0 |
| P2171-036-1206-P3097-X | 3000K | 90 | 2040 | 2194 | 119 | 34.0 | |
| P2171-036-1206-P3597-X | 3500K | 85 | 2115 | 2274 | 124 | 34.0 | |
| P2171-036-1206-P4097-X | 4000K | 85 | 2190 | 2355 | 128 | 34.0 | |
| P2171-036-1206-P4595-X | 4500K | 95 | 80 | 2291 | 2463 | 134 | 34.0 |
| P2171-036-1206-P5095-X | 5000K | 80 | 2315 | 2489 | 136 | 34.0 | |
