International quality, Chinese service
Professional LED packaging device product support services
| Product Code |
色温 CCT |
显指 CRI |
Luminous Flux （lm） |
Efficacy （lm/w） |
Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2142-036-1206-P2280-X | 2200K | 80 | 0 | 2517 | 2707 | 147 | 34.0 |
| P2142-036-1206-P2580-X | 2500K | 0 | 2611 | 2808 | 153 | 34.0 | |
| P2142-036-1206-P2780-X | 2700K | 0 | 2705 | 2909 | 158 | 34.0 | |
| P2142-036-1206-P3080-X | 3000K | 0 | 2855 | 3070 | 167 | 34.0 | |
| P2142-036-1206-P3580-X | 3500K | 0 | 2930 | 3151 | 172 | 34.0 | |
| P2142-036-1206-P4080-X | 4000K | 0 | 3006 | 3232 | 176 | 34.0 | |
| P2142-036-1206-P4580-X | 4500K | 0 | 3024 | 3252 | 177 | 34.0 | |
| P2142-036-1206-P5080-X | 5000K | 0 | 3043 | 3272 | 178 | 34.0 | |
| P2142-036-1206-P5780-X | 5700K | 0 | 3043 | 3272 | 178 | 34.0 | |
| P2142-036-1206-P6580-X | 6500K | 0 | 3006 | 3232 | 176 | 34.0 | |
| P2142-036-1206-P2290-X | 2200K | 90 | 50 | 2123 | 2283 | 124 | 34.0 |
| P2142-036-1206-P2590-X | 2500K | 50 | 2217 | 2384 | 130 | 34.0 | |
| P2142-036-1206-P2790-X | 2700K | 50 | 2311 | 2485 | 135 | 34.0 | |
| P2142-036-1206-P3090-X | 3000K | 50 | 2442 | 2626 | 143 | 34.0 | |
| P2142-036-1206-P3590-X | 3500K | 50 | 2517 | 2707 | 147 | 34.0 | |
| P2142-036-1206-P4090-X | 4000K | 50 | 2555 | 2747 | 150 | 34.0 | |
| P2142-036-1206-P4590-X | 4500K | 50 | 2583 | 2777 | 151 | 34.0 | |
| P2142-036-1206-P5090-X | 5000K | 50 | 2611 | 2808 | 153 | 34.0 | |
| P2142-036-1206-P5790-X | 5700K | 50 | 2611 | 2808 | 153 | 34.0 | |
| P2142-036-1206-P6590-X | 6500K | 50 | 2574 | 2767 | 151 | 34.0 | |
| P2142-036-1206-P2797-X | 2700K | 97 | 90 | 1811 | 1947 | 106 | 34.0 |
| P2142-036-1206-P3097-X | 3000K | 90 | 1961 | 2108 | 115 | 34.0 | |
| P2142-036-1206-P3597-X | 3500K | 85 | 2036 | 2189 | 119 | 34.0 | |
| P2142-036-1206-P4097-X | 4000K | 85 | 2111 | 2270 | 124 | 34.0 | |
| P2142-036-1206-P4595-X | 4500K | 95 | 80 | 2201 | 2367 | 129 | 34.0 |
| P2142-036-1206-P5095-X | 5000K | 80 | 2225 | 2393 | 130 | 34.0 | |
